Overlapping plates for covering a roof

This article needs additional citations for verification. Please help improve this article by adding citations to reliable sources. Unsourced material may be challenged and removed. Find sources: "Roof shingle" – news · newspapers · books · scholar · JSTOR (January 2014) (Learn how and when to remove this message)

A roof’s shingles are a roof covering consisting of individual overlapping elements. These elements are typically flat, rectangular shapes laid in courses from the bottom edge of the roof up, with each successive course overlapping the joints below. Shingles are held by the roof rafters and are made of various materials such as wood, slate, flagstone, metal, plastic, and composite materials such as fibre cement and asphalt shingles. Ceramic roof tiles, which still dominate in Europe and some parts of Asia, are still usually called tiles. Roof shingles may deteriorate faster and need to repel more water than wall shingles. They are a very common roofing material in the United States.

Etymology and nomenclature

[edit]

Look up Schindel in Wiktionary, the free dictionary.

Shingle is a corruption of German Schindel meaning a roofing slate.^[1] Shingles historically were called tiles, and shingle was a term applied to wood shingles,^[1] as is still mostly the case outside the US.

Shingles are laid in courses, usually with each shingle offset from its neighbors. The first course is the starter course and the last being a ridge course or ridge slates for a slate roof. The ridge is often covered with a ridge cap, board, piece, or roll,^[2] sometimes with a special ridge vent material.

Overview

[edit]

Roof shingles are almost always highly visible and so are an important aspect of a building's aesthetics in patterns, textures and colors. Roof shingles, like other building materials on vernacular buildings, are typically of a material locally available. The type of shingle is taken into account before construction because the material affects the roof pitch and construction method: Some shingles can be installed on lath where others need solid sheathing (sheeting) on the roof deck. All shingle roofs are installed from the bottom upward beginning with a starter course and the edge seams offset to avoid leaks. Many shingle installations benefit from being placed on top of an underlayment material such as asphalt felt paper to prevent leaks even from wind driven rain and snow and ice dams in cold climates. At the ridge the shingles on one side of the roof simply extend past the ridge or there is a ridge cap consisting of boards, copper, or lead sheeting. An asphalt shingle roof has flexible asphalt shingles as the ridge cap. Some roof shingles are non-combustible or have a better fire rating than others which influence their use, some building codes do not allow the use of shingles with less than a class-A fire rating to be used on some types of buildings. Due to increased fire hazard, wood shingles and organic-based asphalt shingles have become less common than fiberglass-based asphalt shingles. No shingles are water-tight so the minimum recommended roof pitch is 4:12 without additional underlayment materials.^[3]

Asphalt shingles

[edit]

Left: Example of faster asphalt shingle wear along eaves due to channeled water running down the roof. Right: Severe shrinkage resulting in tearing away of entire tabs. Note the exposed nail heads. Water running down the roof can seep around the nails into the interior space.

Main article: Asphalt shingle

In the United States, fiberglass-based asphalt shingles are by far the most common roofing material used for residential roofing applications. In Europe, they are called bitumen roof shingles or tile strips, and are much less common.^[4] They are easy to install, relatively affordable, last 20 to 60 years and are recyclable in some areas. Asphalt shingles come in numerous styles and colors.^[5]

The protective nature of paper and fiberglass asphalt shingles primarily comes from the long-chain petroleum hydrocarbons, while wood shingles are protected by natural oils in the cellulose structure. Over time in the hot sun, these oils soften and when rain falls the oils are gradually washed out of the shingles. During rain, more water is channeled along eaves and complex rooflines, and these are subsequently more prone to erosion than other areas.

Eventually the loss of the oils causes asphalt shingle fibers to shrink and wood shingles to rot, exposing the nail heads under the shingles. Once the nail heads are exposed, water running down the roof can seep into the building around the nail shank, resulting in rotting of underlying roof building materials and causing moisture damage to ceilings and paint inside.

Wood shingles

[edit]

Two basic types of wood shingles are called shingles and shakes. Wood shakes are typically longer and thicker than wood shingles. The main difference is in how they are made, with shingles always being sawn and shakes normally being split, at least on one side.^[6] A wood shake is often more textured, as it is split following the natural grain of the wood rather than sawn against it like the shingle. Untreated wood shingles and shakes have long been known as a fire hazard and have been banned in various places, particularly in urban areas where exterior, combustible building materials contribute to devastating fires known as conflagrations. Modern pressure-impregnated fire retardant treated wood shakes and shingles can achieve a Class B fire rating, and can achieve a Class A rating when used in conjunction with specially designed roof assemblies.^[7]

The use of wooden roof shingles has existed in parts of the world with a long tradition of wooden buildings, especially Scandinavia, and Central and Eastern Europe. Nearly all the houses and buildings in colonial Chiloé were built with wood, and roof shingles were extensively employed in Chilota architecture.

Slate shingles are also called slate tiles, the usual name outside the US. Slate roof shingles are relatively expensive to install but can last 80 to 400 years depending on the quality of the slate used, and how well they are maintained. The material itself deteriorates only slowly, and may be recycled from one building to another.

The primary means of failure in a slate roof is when individual slates lose their peg attachment and begin to slide out of place. This can open up small gaps above each slate. A secondary mode of failure is when the slates themselves begin to break up. The lower parts of a slate may break loose, giving a gap below a slate. Commonly the small and stressed area above the nail hole may fail, allowing the slate to slip as before. In the worst cases, a slate may simply break in half and be lost altogether. A common repair to slate roofs is to apply 'torching', a mortar fillet underneath the slates, attaching them to the battens. This may apply as either a repair, to hold slipping slates, or pre-emptively on construction.

Where slates are particularly heavy, the roof may begin to split apart along the roofline. This usually follows rot developing and weakening the internal timbers, often as a result of poor ventilation within the roof space. An important aspect to slate roofs is the use of a metal flashing which will last as long as the slates. Slate shingles may be cut in a variety of decorative patterns and are available in several colors.

Flagstone shingles are a traditional roofing material. Some stone shingles are fastened in place but some simply are held by gravity, so the roof pitch cannot be too steep or the stones will slide off the roof. Sandstone has also been used to make shingles.

•
  Slate roofers guild emblem as an ornament made with slate roof shingles, Meerbusch, Germany. Note the hip shingles act as a ridge cap.
•
  A typical flagstone roof in Kastanitsa, Greece.
•
  A dry laid stone roof in Switzerland

Fibre cement shingles are often known by their manufacturer's name, such as Eternit or Transite. Often, the fiber in the cement material was asbestos, the use of which has been banned since the 1980s, for health reasons. The removal of shingles containing asbestos requires extra precautions and special disposal methods.

Metal shingles are a type of roofing material that offers the appeal of traditional shingles, such as wood, tile, and slate, while providing high fire resistance and durability. They are crafted from durable heavy-gauge aluminum and designed to emulate the classic appearance of traditional slate, cedar shingles, and other materials. Metal shingles are extremely fire resistant, so are used in fire prone areas. ^[8]

Plastic has been used to produce imitation slate shingles. These are lightweight and durable, but combustible. Also, they are very lightweight and are one of the cheapest shingles to have installed.^[9]

Cedar shingles are resistant to rot and commonly available in lengths of 18 and 24 inches (460 and 610 mm). These fade gradually from natural wood colored to a silver-like tone. Types include hand-split resawn shakes, tapersplit shakes or tapersawn shakes.

Composite or synthetic shingles are a relatively new type of shingle material that are made from a blend of materials, including asphalt, fiberglass, and other polymers. These shingles are designed to mimic the look of natural materials such as wood, slate, or clay and aim to increase the durability, strength, and resistance to weather elements relative to these natural materials. Some examples of manufacturers of synthetic or composite roof shingles are DaVinci Roofscapes or Unified Steel.

Rubber shingle roofs are typically made from 95% recycled material from a variety of sources including recycled tires. They last twice as long as asphalt shingles but are about twice the price as asphalt. They are more quiet than most roofs, hail resistant, and a high wind rating if there is a tongue and groove fitting at the front edge of the rubber shingle design.^[10][11]

• Roof tiles
• Metal roof
• Roof cleaning
• Shingle style
• Solar shingle
• Asphalt shingle
• Shingles

Wikimedia Commons has media related to Shingle roofs.

Top covering of a building

"Rooftop" redirects here. For other uses, see Rooftop (disambiguation) and Roof (disambiguation).



This article needs additional citations for verification. Please help improve this article by adding citations to reliable sources. Unsourced material may be challenged and removed. Find sources: "Roof" – news · newspapers · books · scholar · JSTOR (June 2012) (Learn how and when to remove this message)

A roof (pl.: roofs or rooves) is the top covering of a building, including all materials and constructions necessary to support it on the walls of the building or on uprights, providing protection against rain, snow, sunlight, extremes of temperature, and wind.^[1] A roof is part of the building envelope.

The characteristics of a roof are dependent upon the purpose of the building that it covers, the available roofing materials and the local traditions of construction and wider concepts of architectural design and practice, and may also be governed by local or national legislation. In most countries, a roof protects primarily against rain. A verandah may be roofed with material that protects against sunlight but admits the other elements. The roof of a garden conservatory protects plants from cold, wind, and rain, but admits light.

A roof may also provide additional living space, for example, a roof garden.

Etymology

[edit]

Old English hrof^[2] 'roof, ceiling, top, summit; heaven, sky', also figuratively, 'highest point of something', from Proto-Germanic *khrofam (cf. Dutch roef 'deckhouse, cabin, coffin-lid', Middle High German rof 'penthouse', Old Norse hrof 'boat shed'). There are no apparent connections outside the Germanic family. "English alone has retained the word in a general sense, for which the other languages use forms corresponding to OE. þæc thatch".^[3]

Design elements

[edit]

The elements in the design of a roof are:

• the material
• the construction
• the durability

The material of a roof may range from banana leaves, wheaten straw or seagrass to laminated glass, copper (see: copper roofing), aluminium sheeting and pre-cast concrete. In many parts of the world ceramic roof tiles have been the predominant roofing material for centuries, if not millennia. Other roofing materials include asphalt, coal tar pitch, EPDM rubber, Hypalon, polyurethane foam, PVC, slate, Teflon fabric, TPO, and wood shakes and shingles.

The construction of a roof is determined by its method of support and how the underneath space is bridged and whether or not the roof is pitched. The pitch is the angle at which the roof rises from its lowest to its highest point. Most US domestic architecture, except in very dry regions, has roofs that are sloped, or pitched. Although modern construction elements such as drainpipes may remove the need for pitch, roofs are pitched for reasons of tradition and aesthetics. So the pitch is partly dependent upon stylistic factors, and partially to do with practicalities.

Some types of roofing, for example thatch, require a steep pitch in order to be waterproof and durable. Other types of roofing, for example pantiles, are unstable on a steeply pitched roof but provide excellent weather protection at a relatively low angle. In regions where there is little rain, an almost flat roof with a slight run-off provides adequate protection against an occasional downpour. Drainpipes also remove the need for a sloping roof.

A person that specializes in roof construction is called a roofer.

The durability of a roof is a matter of concern because the roof is often the least accessible part of a building for purposes of repair and renewal, while its damage or destruction can have serious effects.

Form

[edit]

The shape of roofs differs greatly from region to region. The main factors which influence the shape of roofs are the climate and the materials available for roof structure and the outer covering.^[4]

The basic shapes of roofs are flat, mono-pitched, gabled, mansard, hipped, butterfly, arched and domed. There are many variations on these types. Roofs constructed of flat sections that are sloped are referred to as pitched roofs (generally if the angle exceeds 10 degrees).^[5] Pitched roofs, including gabled, hipped and skillion roofs, make up the greatest number of domestic roofs. Some roofs follow organic shapes, either by architectural design or because a flexible material such as thatch has been used in the construction.

There are two parts to a roof: its supporting structure and its outer skin, or uppermost weatherproof layer. In a minority of buildings, the outer layer is also a self-supporting structure.

The roof structure is generally supported upon walls, although some building styles, for example, geodesic and A-frame, blur the distinction between wall and roof.

The supporting structure of a roof usually comprises beams that are long and of strong, fairly rigid material such as timber, and since the mid-19th century, cast iron or steel. In countries that use bamboo extensively, the flexibility of the material causes a distinctive curving line to the roof, characteristic of Oriental architecture.

Timber lends itself to a great variety of roof shapes. The timber structure can fulfil an aesthetic as well as practical function, when left exposed to view.

Stone lintels have been used to support roofs since prehistoric times, but cannot bridge large distances. The stone arch came into extensive use in the ancient Roman period and in variant forms could be used to span spaces up to 45 m (140 ft) across. The stone arch or vault, with or without ribs, dominated the roof structures of major architectural works for about 2,000 years, only giving way to iron beams with the Industrial Revolution and the designing of such buildings as Paxton's Crystal Palace, completed 1851.

With continual improvements in steel girders, these became the major structural support for large roofs, and eventually for ordinary houses as well. Another form of girder is the reinforced concrete beam, in which metal rods are encased in concrete, giving it greater strength under tension.

Roof support can also serve as living spaces as can be seen in roof decking. Roof decking are spaces within the roof structure that is converted into a room of some sort.

This part of the roof shows great variation dependent upon availability of material. In vernacular architecture, roofing material is often vegetation, such as thatches, the most durable being sea grass with a life of perhaps 40 years. In many Asian countries bamboo is used both for the supporting structure and the outer layer where split bamboo stems are laid turned alternately and overlapped. In areas with an abundance of timber, wooden shingles, shakes and boards are used, while in some countries the bark of certain trees can be peeled off in thick, heavy sheets and used for roofing.

The 20th century saw the manufacture of composition asphalt shingles which can last from a thin 20-year shingle to the thickest which are limited lifetime shingles, the cost depending on the thickness and durability of the shingle. When a layer of shingles wears out, they are usually stripped, along with the underlay and roofing nails, allowing a new layer to be installed. An alternative method is to install another layer directly over the worn layer. While this method is faster, it does not allow the roof sheathing to be inspected and water damage, often associated with worn shingles, to be repaired. Having multiple layers of old shingles under a new layer causes roofing nails to be located further from the sheathing, weakening their hold. The greatest concern with this method is that the weight of the extra material could exceed the dead load capacity of the roof structure and cause collapse. Because of this, jurisdictions which use the International Building Code prohibit the installation of new roofing on top of an existing roof that has two or more applications of any type of roof covering; the existing roofing material must be removed before installing a new roof.^[6]

Slate is an ideal, and durable material, while in the Swiss Alps roofs are made from huge slabs of stone, several inches thick. The slate roof is often considered the best type of roofing. A slate roof may last 75 to 150 years, and even longer. However, slate roofs are often expensive to install – in the US, for example, a slate roof may have the same cost as the rest of the house. Often, the first part of a slate roof to fail is the fixing nails; they corrode, allowing the slates to slip. In the UK, this condition is known as "nail sickness". Because of this problem, fixing nails made of stainless steel or copper are recommended, and even these must be protected from the weather.^[7]

Asbestos, usually in bonded corrugated panels, has been used widely in the 20th century as an inexpensive, non-flammable roofing material with excellent insulating properties. Health and legal issues involved in the mining and handling of asbestos products means that it is no longer used as a new roofing material. However, many asbestos roofs continue to exist, particularly in South America and Asia.

Roofs made of cut turf (modern ones known as green roofs, traditional ones as sod roofs) have good insulating properties and are increasingly encouraged as a way of "greening" the Earth. The soil and vegetation function as living insulation, moderating building temperatures.^[8] Adobe roofs are roofs of clay, mixed with binding material such as straw or animal hair, and plastered on lathes to form a flat or gently sloped roof, usually in areas of low rainfall.

In areas where clay is plentiful, roofs of baked tiles have been the major form of roofing. The casting and firing of roof tiles is an industry that is often associated with brickworks. While the shape and colour of tiles was once regionally distinctive, now tiles of many shapes and colours are produced commercially, to suit the taste and pocketbook of the purchaser. Concrete roof tiles are also a common choice, being available in many different styles and shapes.

Sheet metal in the form of copper and lead has also been used for many hundreds of years. Both are expensive but durable, the vast copper roof of Chartres Cathedral, oxidised to a pale green colour, having been in place for hundreds of years. Lead, which is sometimes used for church roofs, was most commonly used as flashing in valleys and around chimneys on domestic roofs, particularly those of slate. Copper was used for the same purpose.

In the 19th century, iron, electroplated with zinc to improve its resistance to rust, became a light-weight, easily transported, waterproofing material. Its low cost and easy application made it the most accessible commercial roofing, worldwide. Since then, many types of metal roofing have been developed. Steel shingle or standing-seam roofs last about 50 years or more depending on both the method of installation and the moisture barrier (underlayment) used and are between the cost of shingle roofs and slate roofs. In the 20th century, a large number of roofing materials were developed, including roofs based on bitumen (already used in previous centuries), on rubber and on a range of synthetics such as thermoplastic and on fibreglass.

• Outer layer
•
  Slate, Jersey
•
  Terracotta tiles, Hungary
•
  Thatch, using rice straw, Japan
•
  Banana leaves, Cameroon
•
  Date palm branches, Neot Semadar, Israel
•
  Metal sheeting, Namibia
•
  Repairing thatch, Gassho-zukuri farmhouse, Japan
•
  Stone used as roofing material in Himachal Pradesh, India
•
  Turf roof in Norway

A roof assembly has more than one function. It may provide any or all of the following functions:
1. To shed water i.e., prevent water from standing on the roof surface. Water standing on the roof surface increases the live load on the roof structure, which is a safety issue. Standing water also contributes to premature deterioration of most roofing materials. Some roofing manufacturers' warranties are rendered void due to standing water.
2. To protect the building interior from the effects of weather elements such as rain, wind, sun, heat and snow.
3. To provide thermal insulation. Most modern commercial/industrial roof assemblies incorporate insulation boards or batt insulation. In most cases, the International Building Code and International Residential Code establish the minimum R-value required within the roof assembly.
4. To perform for the expected service life. All standard roofing materials have established histories of their respective longevity, based on anecdotal evidence. Most roof materials will last long after the manufacturer's warranty has expired, given adequate ongoing maintenance, and absent storm damage. Metal and tile roofs may last fifty years or more. Asphalt shingles may last 30–50 years. Coal tar built-up roofs may last forty or more years. Single-ply roofs may last twenty or more years.
5. Provide a desired, unblemished appearance. Some roofs are selected not only for the above functions, but also for aesthetics, similar to wall cladding. Premium prices are often paid for certain systems because of their attractive appearance and "curb appeal."

Because the purpose of a roof is to secure people and their possessions from climatic elements, the insulating properties of a roof are a consideration in its structure and the choice of roofing material.

Some roofing materials, particularly those of natural fibrous material, such as thatch, have excellent insulating properties. For those that do not, extra insulation is often installed under the outer layer. In developed countries, the majority of dwellings have a ceiling installed under the structural members of the roof. The purpose of a ceiling is to insulate against heat and cold, noise, dirt and often from the droppings and lice of birds who frequently choose roofs as nesting places.

Concrete tiles can be used as insulation. When installed leaving a space between the tiles and the roof surface, it can reduce heating caused by the sun.

Forms of insulation are felt or plastic sheeting, sometimes with a reflective surface, installed directly below the tiles or other material; synthetic foam batting laid above the ceiling and recycled paper products and other such materials that can be inserted or sprayed into roof cavities. Cool roofs are becoming increasingly popular,^[9] and in some cases are mandated by local codes. Cool roofs are defined as roofs with both high reflectivity and high thermal emittance.^[9]

Poorly insulated and ventilated roofing can suffer from problems such as the formation of ice dams around the overhanging eaves in cold weather, causing water from melted snow on upper parts of the roof to penetrate the roofing material. Ice dams occur when heat escapes through the uppermost part of the roof, and the snow at those points melts, refreezing as it drips along the shingles, and collecting in the form of ice at the lower points. This can result in structural damage from stress, including the destruction of gutter and drainage systems.

The primary job of most roofs is to keep out water. The large area of a roof repels a lot of water, which must be directed in some suitable way, so that it does not cause damage or inconvenience.

Flat roof of adobe dwellings generally have a very slight slope. In a Middle Eastern country, where the roof may be used for recreation, it is often walled, and drainage holes must be provided to stop water from pooling and seeping through the porous roofing material.

While flat roofs are more prone to drainage issues, poorly designed or textured sloping roofs can face similar problems.^[10] Standing water on a roof can lead to mold growth, which is highly damaging to both the building’s structure and the health of its occupants. Repairing drainage issues is significantly less costly than fixing the damage caused by mold.^[11]

Similar problems, although on a very much larger scale, confront the builders of modern commercial properties which often have flat roofs. Because of the very large nature of such roofs, it is essential that the outer skin be of a highly impermeable material. Most industrial and commercial structures have conventional roofs of low pitch.

In general, the pitch of the roof is proportional to the amount of precipitation. Houses in areas of low rainfall frequently have roofs of low pitch while those in areas of high rainfall and snow, have steep roofs. The longhouses of Papua New Guinea, for example, being roof-dominated architecture, the high roofs sweeping almost to the ground. The high steeply-pitched roofs of Germany and Holland are typical in regions of snowfall. In parts of North America such as Buffalo, New York, United States, or Montreal, Quebec, Canada, there is a required minimum slope of 6 in 12 (1:2, a pitch of 30°).

There are regional building styles which contradict this trend, the stone roofs of the Alpine chalets being usually of gentler incline. These buildings tend to accumulate a large amount of snow on them, which is seen as a factor in their insulation. The pitch of the roof is in part determined by the roofing material available, a pitch of 3 in 12 (1:4) or greater slope generally being covered with asphalt shingles, wood shake, corrugated steel, slate or tile.

The water repelled by the roof during a rainstorm is potentially damaging to the building that the roof protects. If it runs down the walls, it may seep into the mortar or through panels. If it lies around the foundations it may cause seepage to the interior, rising damp or dry rot. For this reason most buildings have a system in place to protect the walls of a building from most of the roof water. Overhanging eaves are commonly employed for this purpose. Most modern roofs and many old ones have systems of valleys, gutters, waterspouts, waterheads and drainpipes to remove the water from the vicinity of the building. In many parts of the world, roofwater is collected and stored for domestic use.

Areas prone to heavy snow benefit from a metal roof because their smooth surfaces shed the weight of snow more easily and resist the force of wind better than a wood shingle or a concrete tile roof.

• Insulation, drainage and solar roofing
•
  Snow on the roofs of houses in Poland
•
  The flat roofs of the Middle East, Israel
•
  Steeply pitched, gabled roofs in Northern Europe
•
  The overhanging eaves of China
•
  Green roof with solar panels, Findhorn, Scotland

This section does not cite any sources. Please help improve this section by adding citations to reliable sources. Unsourced material may be challenged and removed. (September 2021) (Learn how and when to remove this message)

Newer systems include solar shingles which generate electricity as well as cover the roof. There are also solar systems available that generate hot water or hot air and which can also act as a roof covering. More complex systems may carry out all of these functions: generate electricity, recover thermal energy, and also act as a roof covering.

Solar systems can be integrated with roofs by:

integration in the covering of pitched roofs, e.g. solar shingles,

mounting on an existing roof, e.g. solar panel on a tile roof,

integration in a flat roof membrane using heat welding (e.g. PVC) or

mounting on a flat roof with a construction and additional weight to prevent uplift from wind.

• Roof shapes
•
  Five roofs of Toji-ji, Kyoto
•
  Pitched roof with decorated gable, Chiang Mai, Thailand
•
  Säteri roof (with vertical break in pitch), Sweden
•
  Mansard roof, county jail, Mount Gilead, Ohio
•
  Conical roof, Nanhai Academy in Taipei
•
  Flat roofs, Haikou City, Hainan, China
•
  Sloped flat roof, house, Western Australia
•
  Butterfly roof in Paradise Palms in the southwestern United States

•
  The polychrome tiles of the Hospices de Beaune, France.
•
  The glazed ceramic tiles of the Sydney Opera House.
•
  Ashlar masonry dome of the Great Mosque of Kairoun, Tunisia
•
  Imbrex and tegula tiles on the dome of Florence Cathedral.
•
  The marble dome of the Taj Mahal.
•
  The copper roof of Speyer Cathedral, Germany.
•
  The lead roof of King's College Chapel, England.
•
  The glass roof of the Grand Palais, Paris.
•
  A slate roof in Syrrako (Greece), built with a curved valley layout and finials on top.
